Fittings Kit Includes:
Our range of 304 Stainless Steel post bases are designed to be resistant to extreme exposure to the elements. By keeping the timber post above the ground level out of the damp areas and allowing the post foot to dry out after rain it helps prevent decay and prolong the life of the post. Bottom plate 155mm x 155mm x 12mm, 326mm high, post plate 120mm x 120mm x 8mm, verticle fixing plate 110mm x 90mm x 8mm, weight 5kg- Axial load of 2.36kn (240kg), Lateral load of 3.4kn (346kg) based on on the canopy roof details contained within our PDF drawing P1. SSBFH0
Technical- IMPORTANT. Please note on all our range of stainless steel post bases the maximum safe height above the finished floor level for any of the post supports is 200 mm. The post is designed for use with Timber engineered buildings. The post bases have a base plate with a central tube post welded to the base plate and the load bearing plate. A fxing plate is welded centrally over the load bearing plate. The base plate has four 14mm holes, 28mm centres from the edge to receive 12mm fixings. The fixing plate has four 10mm holes to recieve 9.5mm dowels of your choice. The visible tube part is brush polished.
Price exclude delivery, product is available for next day delivery
Optional fixing kit available see fixings section
• F-A-TF3 900mm high ex 75mm x 75mm.
•Turned Accoya Wood finials with ball caped conical finial, a ball mount to the top and a ball pendant to the bottom, stop bevelled.
•Accoya Wood 100% FSC-COC. The material is covered with a 50 year above ground guarantee, subject to fixing and treatment conditions.
•Technical- Finish Planed all round timber. All seen surfaces are twice sanded (80s grit and 100s grit) sandpapers, all arises are removed with glass-paper. Structural Suitability- Not structural. Dip treated with Protim microporous stain.
•Delivery- usually dispatched for next day delivery.
